Inverter LS SV0037iS7-2NO – iS7 Series
This product belongs to LS’s high-performance iS7 inverter line designed for controlling 3-phase motor applications in low-voltage ranges.
Power supply: 3-phase, voltage range from 200 to 230V, frequency 50–60Hz
Output frequency: Adjustable from 0.01Hz to 400Hz
Rated power: 3.7kW, equivalent to 5 HP
Output capacity: Up to 6.1kVA, suitable for medium to high-load systems
Rated input current:
Constant Torque (CT) mode: 24A
Variable Torque (VT) mode: 21.8A
Rated output current:
CT: 16A
VT: 24A
Connection diagram of SV0037IS7-2NO
Product structure of SV0037IS7-2NO
Applications of SV0037IS7-2NO
SV0037iS7-2NO inverter belongs to iS7 Series and is widely used in production systems and industrial facilities. With precise speed control capability, this equipment is suitable for many types of machinery and production lines operating in industries such as:
- Machinery & Fabrication: grinders, rolling mills, pulling machines, film coating machines, fiber forming machines
- Plastics – Rubber – Chemicals – Coating industries
- Textile – Dyeing – Packaging
- Wood processing – Food
- Drive systems – Conveyors – Cooling towers – Cranes – Lifting equipment
- Air compressors – Industrial pumps and fans
The inverter enables efficient load control and is equipped with multiple protection functions such as: overload, overcurrent, overheating, overvoltage, undervoltage, as well as phase loss and phase imbalance detection — ensuring device safety and reliable operation.
